KAWASAKI FX691V-FS14-S 22HP ENGINE

The Kawasaki FX691V-FS14-S engine is a 22HP commercial-grade V-Twin engine designed for professional mowing, turf care, and industrial equipment. Built to outperform competing engines in high-load environments, the FX691V delivers strong horsepower, smooth operation, and dependable long-term performance.

Featuring a 4-stroke, air-cooled, horizontal shaft OHV design, this engine is engineered for durability and efficiency. Cast-iron cylinder liners, a dual-element heavy-duty air cleaner, and an internally vented carburettor ensure consistent fuel delivery and extended engine life, even in dusty or demanding conditions.

An integrated oil cooler and high-performance lubrication system help manage operating temperatures during long run times, making this engine a trusted choice for commercial and industrial users who require reliability without compromise.

Ideal for equipment rebuilds, mower upgrades, or industrial machinery where dependable Kawasaki power is essential.

Key Features

• 22HP Kawasaki commercial-grade V-Twin engine

• 4-stroke, air-cooled OHV design

• Horizontal shaft configuration

• Cast-iron cylinder liners for long service life

• Dual-element heavy-duty air cleaner

• Internally vented carburettor for stable fuel delivery

• Integrated oil cooler for temperature control

• High-performance lubrication system

• Built for commercial and industrial workloads

Technical Specifications

• Engine Type: Air-cooled, 4-stroke, horizontal shaft, OHV

• Number of Cylinders: 2

• Bore × Stroke: 75.2 × 76 mm

• Displacement: 675 cc

• Maximum Power: 16.0 kW (21.4 HP) @ 3600 RPM

• Maximum Torque: 48.2 Nm (35.5 ft-lb) @ 2400 RPM

• Oil Capacity: 1.6 litres

• Dry Weight: 44.5 kg

• Dimensions (L × W × H): 349 × 430 × 492 mm

Compatibility & Applications

• Commercial mowing equipment

• Industrial machinery

• Turf and grounds maintenance equipment

Suitable for applications requiring a Kawasaki FX-Series 22HP horizontal shaft engine. Always confirm shaft size and mounting requirements before purchase.

Why Choose the FX691V-FS14-S?

• Proven Kawasaki reliability in commercial environments

• Strong torque for heavy-duty applications

• Efficient cooling for extended operating hours

• Built to outperform standard residential engines
